VHF Marine Handheld Transceiver

VHF Marine Handheld Transceiver

18600.00 INR/Piece

Product Details:

  • Product Type Security Equipment
  • Material Plastic
  • Supply Ability : 1 Per Day
  • Click to view more
X

Price And Quantity

  • 18600.00 INR/Piece
  • 1 Piece

Product Specifications

  • Plastic
  • Security Equipment

Trade Information

  • Cheque, Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Paypal
  • 1 Piece Per Day
  • 1 Days
  • Yes
  • Contact us for information regarding our sample policy
  • Standard
  • Asia
  • All India
  • ISO 9001"2015

Product Description

VHF Marine Handheld Transceiver

Our company presents a wide range of VHF Marine Handheld Transceiver.  This transceiver is integrated with a flashing light that activates when the radio hits water. It is also designed with a large, easy to read LCD screen which offers a clear 2-digit channel number indication. In this VHF Marine Handheld Transceiver, we have completely eliminated the exposed metal charging points which ensures protection from water damage.

Features:

  • Easy to change the volume level to capture the received message
  • Comes with accurate weather alert
  • Built tough with super strong aluminum alloy chassis

Features

  • 128 channels to program operating parameters via PC utility software
  • Channel, Name tag and VFO (Frequency) display modes selectable
  • Comes with a rechargeable Li-Ion pack, quick stand-charger and high-performance whip antenna
  • Ergonomically designed compact body 59.0W x 98.0H x 35.0D mm or 2.32W x 3.86H x 1.38D inches (w/o projections, approx.), weighs approx.227g or 8.01oz inclusive of battery pack and antenna
  • 3 types of Scan functions (VFO/Memory channels/Priority), 50 CTCSS, 116 DCS and 4 Tone-burst tones
  • Backlit, Dot Matrix LCD screen with alphanumeric name tag
  • Microphone and speaker ports
  • Includes FM radio receiver, Internal VOX, Voiceprompt in English, Remote-Kill/Stun/Waken, Analog scrambling, Voice Compounder, Narrow FM, Repeater-reverse, Auto-Power-OFF, Busy-Channel Lockout, Time-Out-Timer and more and more at No extra costs

Specifications:

General

  • Frequency coverage
    • (TX/RX)136.000-173.995MHz
    • (RX only) 76-108MHz
  • ModeF3E(16K0F3E / 11K0F3E / RX only WFM)
  • Programmable channels 128 channels
  • Frequency stability ±2.5ppm
  • Power supply requirement 7.4V DC±20% (negative ground)
  • Current drain (Approx.)1400mA TX / 300mA receive at Max audio output / 70 mA squelched
  • Usable temperature range 20+55 (-4-131°F)
  • Dimensions (Projections not included/approx.)59.0W 98.0H 35.0D mm or 2.32W 3.86H 1.38D inches
  • Weight : approx.227g or 8.01oz inclusive of battery pack and antenna
  • Transmitter (ETSI EN300 086 compliant)
  • Output power Approx.5 / 2 / 0.5W
  • Modulation system Variable reactance FM
  • Spurious emissions Less than 36dB
  • Max. frequency deviation ±5kHz / ±2.5kHz
  • Receiver (ETSI EN300 086 compliant)
  • Receive system Double conversion superheterodyne
  • Intermediate frequencies 38.85MHZ
  • Sensitivity(12dB SINAD Wide/Narrow)
    • 12dB or better
    • (0.25V/0.35V) or better
  • Selectivity 6dB : 6dB : Wide 12kHz /Narrow 10kHz or more
  • 60dB :Wide 30kHz / Narrow 24kHz or less
  • Audio output power1000mW(8 / Max)

Gvtel Communication System
