ICOM Air Band Walkie Talkie

About ICOM Air Band Walkie Talkie

VHF Air Band Transceiver

Tough and reliable construction
The lC-F14/S series is built around an aluminum die-cast chassis and covered with tough polycarbonate casing. This radio is built to last. Its dual slide rail securely locks the battery to the radio. The battery terminal is covered with a non-corrosive rubber packing. The belt clip is clamped between the radio and the battery, making it nearly impossible to knock loose.
Simple operation
Having only 3 buttons, volume and channel knobs, the lC-F14/S series does not require special training to use. Positive button action for sure operation even when wearing gloves, allows you to get down to the business of communicating without fuss.
Wide frequency coverage
The IC-F14/S series covers a wide frequency range with one version (136-174, 400-470, 450-512 (520) MHz). Wide and narrow channel spacing (25, 12.5kHz) is programmable per channel.
Lithium-Ion battery standard
The lC-F14/S series comes with a high capacity 20oomAh (typ.) Li-lon battery pack, BP-232N, as standard. Li-lon batteries have virtually no memory issues and allows you flexible charging.
Optional board
The lC-F14/S series has an expansion socket for adding an optional board. Voice scrambler, man down and DTMF decoder features are available, depending on the installed board.
Most popular signalings built-in
Use the built-in 2-Tone, 5-Tone, CTCSS and DTCS capabilities as standard to set up your own talk groups and quiet stand-by when others are talking.
Multiple 2-Tone, Multiple 5-Tone
Up to 10 2-Tone/8 5-Tone codes can be decoded on a channel. When a matched tone is received, the following items are programmable for each code.

• Beep sound
• Answer back
• Stun
• LED blink
• Scan

Other features

• MDC PTT ID and MDC emergency call functions are available (Transmit only)
• LED low battery alert
• TOT function and lock out penalty timer
• 2 step power saver
• Normal and priority scan
• 500mW loud and clear audio
• Optional VOX headset
• PC programming capability
