Alinco Walkie Talkie

About Alinco Walkie Talkie

Alinco Walkie Talkie

Alinco has created a new 2 meter HT that sets new standards in features, convenience and easy operation. The DJ-175 sports an alphanumeric display for easy memory management. It has an ergonomic design thatsuser friendlyand the 5-watt output battery is standard. Be prepared for virtually any selective calling situation or gaining access to repeaters with 39-tone CTCSS, 104 DCS, Tone-bursts and DTMF encoding, all included at No extra costs. Best of all, DJ-175 retains the proud Alinco tradition of quality construction and excellent value.

• Two-touch Repeater Access
• Rugged polycarbonate body
• Highly visible backlit alphanumeric display
• Direct frequency input through illuminated keypad
• 200 memories plus 1 CALL channel
• VFO, Memory and Scan modes
• Ultra-exible antenna with SMA port
• CTCSS encode+decode / 39 tones
• DCS encode+decode / 104 codes
• 1000,1450,1750 and 2100Hz Tone-bursts
• Battery-drain functions avoids memory-eect
• Ergonomic design, ts in the palm of your hand
• Wire-cloning capability
• 3 levels of output power (5 / 2 / 0.5W)
• Clean, crisp and powerful 500mW Audio


Specifications:

General Frequency coverage

(T)
TX 144147.995MHz *144147.995MHz
RX 136173.995MHz *144147.995MHz
(E)
TX 144145.995MHz *144145.995MHz
RX 144145.995MHz *144145.995MHz
(TFH) TX 136173.995MHz *150173.995MHz
RX 136173.995MHz *150173.995MHz
* Guaranteed range per Specifications
ModeF3E (FM) / F2D, T/E models only
Frequency steps5, 10, 12.5, 20, 25 & 30KHz
Memory channels200 channels + 1 CALL channel + 1 Repeater-Access function memory
Antenna connector50 unbalanced
Frequency stability2.5ppm
Microphone impedance : 2k nominal

Power supply requirement

• 7.2V Battery only / External DC port is NOT available.

Current drain (Approx.) :

• 1.5A Transmit high at 5W
• 250mA Receive at 500mW
• 70mA Stand-by
• 30mA Battery save on
• Usable temperature range10+45C (+14113F)
• Dimensions58(W)107.5(H)36.3(D) mm
• 2.28(W)4.23(H)1.43(D) inches
• WeightApprox. 245g/ 8.7oz with EBP-72 & antenna

Transmitter

• Output power (Approx.) : 5W (High)/ 2W (Middle)/ 0.5W (Low)
• Modulation systemVariable reactance frequency modulation
• Spurious emissions60dB or less
• Max.frequency deviation5KHz 2.5KHz (Narrow band model

Receiver

• Receive systemDouble conversion superheterodyne
• Intermediate frequencies1st: 21.7MHz / 2nd: 450KHz
• Sensitivity(12dB SINAD)14dB (0.2V)
• Selectivity6dB: 12KHz or more /60dB: 26KHz or less
• 6dB: 6KHz or more / 60dB: 14KHz or less (Narrow band model
• Audio output power500mW (8, MAX)/400mW (8, 10% THD)
• Narrow-FM models avaiable depending on areas of distribution.

GVTEL Communication Systems specializes in supplying Alinco Walkie Talkie systems. These are integrated with varied and extensive features which enhances their demand in the market making them a hot seller. Our efficient team and quality experts supply a plethora of these sets on a large scale. These handheld communication systems are designed and manufactured under strict guidelines provided by our proficient auditors using the supreme quality of raw materials. These Wireless Walkie Talkies are compact in size, user-friendly and are light-in-weight.

Alinco Walkie Talkie systems have diverse features:

• Extensive channel capacity
• Good power output
• Battery save feature
• Alert on low battery
• Emergency alarm
• Busy channel update
• Light weight


Alinco Wireless Walkie Talkie systems are manufactured with state-of-the-art technology and high grade premium raw material as per the industrial norms. Moreover, our products are available at competitive prices.
